TPR22-BM-EX Belt Misalignment Switches

TPR22-BM-EX

  • Ex Zone 11 and 21 Zone
  • BMC Composite Body is not oxidized!
  • It is resistant to blow and heavy conditions.
  • Alarm and Stop Angle Option
  • It has CE and EAC Standards.
Get offer 3D Model Share
TPR22-BM-EX Belt Misalignment Switches

TPR22-BM-EX BeltMisalignment Switch is a conveyor belt safety accessory designed to alarm and/or shut down conveyor systems in the event of a conveyor belt misalignment.

TPR22-BM-EX series of conveyor belt pull cord switch do not require maintenance.

Materials used:

The Body structure is made of BMC composite material. It is resistant to corrosion and explosive gas. Shaft mechanisms are made of stainless steel. The handle mechanism is cylindrical in structure and operates with two bearings.

Uses and Applications:

It is mounted on both sides of the conveyor belt to be attached to the chassis. If the belt begins to deviate, it makes contact with the roller arm causing it to spin. As more force is applied to the roller arm, it will rotate away from the normal position.

At a 15°, it will actuate the first alarm microswitch. The first microswitch will annunciate the alarm condition to the control system. If the belt continues to slip, the system is stopped by activating the second microswitch at a 35 ° position.

Safety Features:

The heavy-duty rugged design makes them suitable for most industrial applications. It can be used with only one contact mechanism without using alarm contact.

General Description:

The roller arm of the switch is placed about 15 cm away from the normal belt position.

Available modifications as per request:

-           The alarm contact structure can be added

Certifications and Standards:

The microswitch used in products is VDE approved. All KBT Electric products are produced in accordance with CE and EAC standards.

Technicial Specifications

Region Ex Zone 11 ve 21
Body Bmc Hard Composite
Micro Switch Values 400VAC 6A / 230VAC 8A / 24VDC 10A
Output Signal (1) SPDT shutdown, alarm can be added upon request.
Cable Entry 2xM25
Connector M25 Ex Gland
Temperature Rating -30°C - +85°C
Movement Angle 15° ve 35°
Contact Status Snap - Action
Protection Class IP68
Casing Color Black RAL 7021
Weigh 3.1 Kg
Mounting Structure It is suitable for double-sided use.

Security Approvals

Electrical Security EN60947
Mechanical Security EN 60204
Outdoor Security EN 60529
Current Certificate CE
Russia Market EAC
Micro Switch VDE
Explosive Environment EX - Zone 22 / Zone 21

Options

Bus Security Interface
Adjustable Angle
Casting Body
Mounting Feets
Arm Length and Diameter

Ex Definition

EX II 2G Ex db IIC T6/T5 Gb
EX II 2D Ex tb IIIC
T80 °C/T95 °C Db
IECEx Ex db IIC T6/T5 Gb
Ex tb IIIC T80 °C/T95 °C Db

Model Specifications List

Model Alarm Stop Reset
NC NO Angle NC NO Angle​
TPR22-BM-EX     15° 1 1 35° Avaible
TPR22-BM-A01-EX     15° 1 1 35° **
TPR22-BM-A11-EX 1 1 15° 1 1 35° Avaible
TPR22-BM-A11B-EX 1 1 15° 1 1 35° **
TPR22-BM-22-EX     15° 2 2 35° Avaible
TPR22-BM-A02-EX     15° 2 2 35° **
TPR22-BM-A22-EX 2 2 15°     35° Avaible
TPR22-BM-A22B-EX 2 2 15°     35° **
TPR22-BM-33-EX     15° 3 3 35° Avaible
TPR22-BM-A03-EX     15° 3 3 35° **
TPR22-BM-A33-EX 3 3 15°     35° Avaible
TPR22-BM-A33B-EX 3 3 15°     35° **

Spare Parts Accessories List

KB-826-EX 1NO+1NC Switch
KB-826-02-EX 2NO+2NC Switch
KB-826-03-EX 3NO+3NC Switch
KB-R-01-EX M25x1,5 Cable Gland
KB-KT-01-EX M25 Blind Plug
KB-4-KN-EX 4 Pin Connector
BA-11 Connection Mounting  Foot
KB-TGV-01-EX Body Cover
TSR-42-BM-EX Bearing Stainless Arm
KB-PM-EX Reset Lever
